Platform drivers were one of the first success stories of the Rust-for-Linux project. They were a proof of concept that the integration of Rust into the existing Linux kernel C code base would work. The decision to focus on platform drivers early on was strategic. They are simpler compared to complex GPU or network drivers, and therefore provide a perfect sandbox for testing Rust abstractions.

Therefore, we want to show the callback conundrum based on the Rust implementation of the platform driver base rust/kernel/platform.rs in Linux kernel Version 7.0 of Linux Torvald’s tree.

The function of void *user_data

Most C callback functions have the following signature: void register_callback(void (*cb)(int, void*), void* user_data);. This signature is a common C pattern to pass a private state or context to a stateless function pointer. You can imagine the user_data like a bucket of bytes, that has no information for the calling function of the callback in C. The usage of user_data is a way of handling the lack of native polymorphism and inheritance in C.

The userdata is usually cast to a driver dependent struct, depending on which driver callback was called, and contains the private state of a specific instance of a device. A single gpio controller driver can be managing several identical pieces of hardware at once. The user data is the “memory” that tells the driver which one of them it is currently talking to. Therefore, this user data pointer often times points to information like the hardware resource mapping ¹, state management ², back pointers to the parent device or parent system ³, as well as buffer and queues ⁴.

Let’s look at drivers/platform/goldfish/goldfish_pipe.c for a code example. The goldfish driver provides a very fast communication channel between the guest system and the QEMU emulator. In the call of the open callback function for this device driver, the field private_data is initialized with a pointer to the goldfish specific struct goldfish_pipe. When the device disappears, the release function is called which resets private_data to NULL.

static int goldfish_pipe_open(struct inode *inode, struct file *file)
{
    /* Allocate new pipe kernel object */
    struct goldfish_pipe *pipe = kzalloc_obj(*pipe);
...
  file->private_data = pipe;
...
}

static int goldfish_pipe_release(struct inode *inode, struct file *filp)
{
...
  file->private_data = NULL;
...
}

When callback functions like read, write, poll are called, the device specific struct is retrieved again to be used in the function.

static ssize_t goldfish_pipe_read_write(struct file *filp,
    char __user *buffer,
    size_t bufflen,
    int is_write)
{
struct goldfish_pipe *pipe = filp->private_data;
    ...
}

Note: While this example uses file->private_data, the pattern is equivalent to void* user_data in callback registration. Both pieces of code serve to pass driver-specific state to the handler.

You might wonder now, how does Rust handle this use case in a explicit and type-safe way?

Rustification of user_data

Rust is based on the principles of ownership and thread safety. If we want a state to be passed to a C function, we must make sure it is in the heap and cannot be moved around by the Rust compiler. This is why the driver specific data is allocated in a Box and pinned. The Box reserves memory on the heap for our user data. The pinning makes sure, that the data in the box cannot be moved out. For the C code, the user data is a black box. When the Rust driver probes a new device and calls set_drvdata, it effectively hands a pointer to “some data” to the C code, which does not have any meaning to it. At the same time, the ownership is also transferred to the C code.

When the C code on occurrence of an interrupt calls the interrupt handler function of our driver, it hands back this opaque data to us. Since we know how to interpret the data, this is where our otherwise generic function gets the context from. If the device is unplugged or disappears, the remove function is called, which also gets passed this black box. It is then the Rust drivers task to free the memory.

Let’s look at rust/kernel/platform.rs.

impl<T: Driver + 'static> Adapter<T> {
    extern "C" fn probe_callback(pdev: *mut bindings::platform_device) -> kernel::ffi::c_int {
        // SAFETY: The platform bus only ever calls the probe callback with a valid pointer to a
        // `struct platform_device`.
        //
        // INVARIANT: `pdev` is valid for the duration of `probe_callback()`.
        let pdev = unsafe { &*pdev.cast::<Device<device::CoreInternal>>() };
        let info = <Self as driver::Adapter>::id_info(pdev.as_ref());

        from_result(|| {
            let data = T::probe(pdev, info);

            pdev.as_ref().set_drvdata(data)?;
            Ok(0)
        })
    }
...
}

The data specific to the specific driver instance is set in pdev.as_ref().set_drvdata(data)?;.

The implementation of set_drvdata can be found in rust/kernel/device.rs. The function into_foreign() is part of the ForeignOwnable trait. It relinquishes ownership of data to the device, which in turn gives the ownership to the C code. It ensures that the Rust object is “pinned” in memory and won’t be dropped by Rust’s borrow checker while the C kernel is handling it.

The code data.into_foreign() converts the data from a Rust Box into a raw pointer, a.k.a *const c_void or a typed pointer *const T. The C kernel API, which is called by using bindings, almost always expects a *mut core::ffi::c_void to be passed as a function argument.

Let’s assume for example that into_foreign() returned a typed pointer *const MyDriverData, while the C function expects a mut void *. Rust is much stricter than C and will therefore not implicitly convert a typed pointer into a generic pointer. Furthermore, into_foreign() often returns a read-only pointer to ensure safety, while many C registration functions expect a *mut void. The program must call cast() explicitly to convert it a generic mutable pointer.

impl Device<CoreInternal> {
...
    /// Store a pointer to the bound driver's private data.
    pub fn set_drvdata<T: 'static>(&self, data: impl PinInit<T, Error>) -> Result {
        let data = KBox::pin_init(data, GFP_KERNEL)?;

        // SAFETY: By the type invariants, `self.as_raw()` is a valid pointer to a `struct device`.
        unsafe { bindings::dev_set_drvdata(self.as_raw(), data.into_foreign().cast()) };
        self.set_type_id::<T>();

        Ok(())
    }
...
}

impl Device<CoreInternal> {
...
    /// Borrow the driver's private data bound to this [`Device`].
    ///
    /// # Safety
    ///
    /// - Must only be called after a preceding call to [`Device::set_drvdata`] and before the
    ///   device is fully unbound.
    /// - The type `T` must match the type of the `ForeignOwnable` previously stored by
    ///   [`Device::set_drvdata`].
    pub unsafe fn drvdata_borrow<T: 'static>(&self) -> Pin<&T> {
        // SAFETY: `drvdata_unchecked()` has the exact same safety requirements as the ones
        // required by this method.
        unsafe { self.drvdata_unchecked() }
    }
}

impl Device<Bound> {
    /// Borrow the driver's private data bound to this [`Device`].
    ///
    /// # Safety
    ///
    /// - Must only be called after a preceding call to [`Device::set_drvdata`] and before
    ///   the device is fully unbound.
    /// - The type `T` must match the type of the `ForeignOwnable` previously stored by
    ///   [`Device::set_drvdata`].
    unsafe fn drvdata_unchecked<T: 'static>(&self) -> Pin<&T> {
        // SAFETY: By the type invariants, `self.as_raw()` is a valid pointer to a `struct device`.
        let ptr = unsafe { bindings::dev_get_drvdata(self.as_raw()) };

        // SAFETY:
        // - By the safety requirements of this function, `ptr` comes from a previous call to
        //   `into_foreign()`.
        // - `dev_get_drvdata()` guarantees to return the same pointer given to `dev_set_drvdata()`
        //   in `into_foreign()`.
        unsafe { Pin::<KBox<T>>::borrow(ptr.cast()) }
    }
...
}

An example of a platform driver that uses platform.rs is to be found in drivers/pwm/pwm_th1520.rs, a T-HEAD TH1520 PWM driver. I guess it is no surprise that the first user of the Rust based platform driver is a RISC-V SoC PWM controller.

The driver’s private data is defined as Th1520PwmDriverData.

#[pin_data(PinnedDrop)]
struct Th1520PwmDriverData {
    #[pin]
    iomem: devres::Devres<IoMem<TH1520_PWM_REG_SIZE>>,
    clk: Clk,
}

When the driver’s probe() function is called, it passes Th1520PwmDriverData to pwm::Chip::new(). Internally, this stores the data via pwmchip_alloc() and constructs it in-place in the private data area.

// drivers/pwm/pwm_th1520.rs, line 368-375
let chip = pwm::Chip::new(
    dev,
    TH1520_MAX_PWM_NUM,
    try_pin_init!(Th1520PwmDriverData {
        iomem <- request.iomap_sized::<TH1520_PWM_REG_SIZE>(),
        clk <- clk,
    }),
)?;

This is the Rust equivalent of C’s void* user_data - the platform adapter stores the driver-specific state and passes it back via drvdata() when the callback is invoked.

impl pwm::PwmOps for Th1520PwmDriverData {
    fn round_waveform_tohw(...) {
        let data = chip.drvdata();  // retrieves Th1520PwmDriverData
        let rate_hz = data.clk.rate().as_hz() as u64;
        // ... use rate to convert ns to cycles
    }
}

As a small side note, I want to mention that the Rust compiler and runtime can only check that the rules and boundaries are enforced in the Rust environment. If the FFI is used to call C functions in an unsafe block, the C code can manipulate the data in memory. The functions into_foreign() and from_foreign(), defined in the trait ForeignOwnable, do provide safe bridges between both programming languages. But by using an unsafe block, you tell the compiler that you will take the responsibility for the safety of the code.

This is also why the implementation is marked as unsafe impl. This mark is placed when the compiler cannot verify that the programmer is following the rules of the trait remarked in the comments.

Furthermore, the file rust/kernel/types.rs contains a default implementation of ForeignOwnable for a stateless driver. If the driver passes () as user data, this implementation makes sure that Rust knows how to turn it back into ’nothing’ gracefully.

The documentation in rust/kernel/types.rs explicitly states, that the only guarantees given about the pointer are, that it has a minimum alignment, and that the return pointer is not null. The pointer could still be invalid, dangling or pointing to uninitialized memory, which the caller of from_foreign needs to handle. Furthermore, the programmer must ensure that the pointer provided to from_foreign must have been returned from a previous call to into_foreign, and that the pointer has not been passed to from_foreign more than once. If the programmer does not uphold this safety contract, we have undefined behavior of the code, as in good old C programs.

The last safety mechanism I want to mention is implemented by the line unsafe impl<T: 'static, A> ForeignOwnable for Box<T, A> { .. } in kbox.rs. In Rust, 'static denotes an “eternal” lifetime. This is the longest possible lifetime a value can have, lasting for the entire duration of the program’s execution. Because of this implementation of ForeignOwnable for Box, the type that is stored in the box needs to have a static lifetime. This prevents using types with borrowed references that cannot safely cross the FFI boundary, which is checked at compile time. In other words, if a type or any of its members contain a non-static lifetime reference at compile time, it would be unsafe to pass to C code since the lifetime cannot outlive the foreign context.

Summary

In C, void* user_data passes context to callbacks but loses type information. Rust replaces this with set_drvdata() + drvdata<T>(), which adds type-safe checks at compile time. The ForeignOwnable trait bridges the worlds between Rust and C language safely.
