In the last blog post, we discussed how callback arguments are handled in Rust when interfacing with C.

When we want to interface with every C context in the Linux kernel using *mut ffi::c_void, we lose the ability to distinguish different types. If we interpret a device context as a driver context, in the best case we run into a segfault. In the worst case, we hunt a bug that only sometimes overwrites our whole file system.

Let’s have a look at rust/library/core/src/marker.rs, where PhantomData is defined.

/// ## Layout
///
/// For all `T`, the following are guaranteed:
/// * `size_of::<PhantomData<T>>() == 0`
/// * `align_of::<PhantomData<T>>() == 1`
///
/// [drop check]: Drop#drop-check
#[lang = "phantom_data"]
#[stable(feature = "rust1", since = "1.0.0")]
pub struct PhantomData<T: PointeeSized>;

The compiler uses PhantomData<T> to find out the lifetime and ownership (variance) of a generic type. It tells the compiler to treat a struct as if it owns a T field, even if it does not actually store one, making sure the C data is not dropped while the Rust struct is still in use. When PhantomData is included in your struct, the pointer cannot automatically be marked as Send or Sync if the underlying C library is not thread-safe.

#[stable(feature = "rust1", since = "1.0.0")]
impl<T: PointeeSized> !Send for *const T {}
#[stable(feature = "rust1", since = "1.0.0")]
impl<T: PointeeSized> !Send for *mut T {}

In theory, you could replace PhantomData with a private field _unused: [u8; 0]. However, you would lose the automatic inheritance of the thread-safety properties of T. We want a type that allows a non-thread-safe library to be marked as not thread-safe by default. Furthermore, if T has a destructor, using PhantomData<T> prevents the compiler’s “drop checker” from destroying the context while the data is still supposedly in use.

The attribute #[lang = "phantom_data"] also marks this struct as a language item, which the compiler needs to know about in order to implement core language features. It provides a “hook” between the library and the compiler. The size of PhantomData is 0, which means it does not take up space in memory. The compiler ensures that PhantomData is a zero-sized type (ZST) and is completely optimized away in the final machine code.

PhantomData<T> makes it possible to introduce type safety while the details of the implementation of the type are still only known to the C library (type erasure).

struct DeviceHandle {
    ptr: *mut c_void,
    _marker: PhantomData<DeviceContext>,
}

struct DriverHandle {
    ptr: *mut c_void,
    _marker: PhantomData<DriverContext>,
}

// The compiler treats these as totally different entities:
fn configure_device(handle: DeviceHandle) { ... }

// This call will fail if you pass a DriverHandle:
// configure_device(my_driver_handle);

Even if both structs might be zero-sized or contain a raw pointer type, the T inside of PhantomData<T> makes them incompatible in the eyes of the type system. If you now want to pass a struct containing DeviceHandle to a function that expects a DriverHandle, the Rust compiler will yell at you.

T has the trait PointeeSized, which tells the compiler that the size of the data is only known at runtime via a pointer. In contrast to this is the Sized trait, where the size is known at compile-time. We have to use PointeeSized, because at compile time we cannot know the size of the struct in the C code.¹

Furthermore, it implements several constructs for all traits that might want to be used in the kernel, like Hash, several versions of Eq (for testing equality) and Ord (for testing smaller than, etc), Copy, and Default, so that we don’t have to.

#[stable(feature = "rust1", since = "1.0.0")]
impl<T: PointeeSized> Hash for PhantomData<T> {
    #[inline]
    fn hash<H: Hasher>(&self, _: &mut H) {}
}

#[stable(feature = "rust1", since = "1.0.0")]
impl<T: PointeeSized> cmp::PartialEq for PhantomData<T> {
    fn eq(&self, _other: &PhantomData<T>) -> bool {
        true
    }
}

The second noteworthy construct is Opaque<T>. Opaque marks FFI objects that are never interpreted by Rust code. It is used for wrapping structs from the C side, and gets rid of all usual assumptions Rust has for a value. So the value may be uninitialized, it is possible that multiple shared references &Opaque<T> exist (while the data it encapsulates can still be modified through internal mutation using UnsafeCell), and the value shall never be shared with other threads (i.e. it is !Sync). This struct has to be used whenever the C side has access to the value, since it can’t be ensured that the C side is adhering to the usual constraints and safeguards that Rust needs.

#[repr(transparent)]
pub struct Opaque<T> {
    value: UnsafeCell<MaybeUninit<T>>,
    _pin: PhantomPinned,
}

This code defines Opaque as a safe wrapper for unsafe memory. It occupies the same space as the C type T (#[repr(transparent)]), can be modified by external C code without the Rust compiler yelling (using UnsafeCell), tells the compiler that the data might be invalid (MaybeUninit) on creation and makes sure that once the struct is created, it stays at a fixed address in memory to prevent pointer corruption.

Let’s have a look at a concrete example where Opaque is used in rust/kernel/iov.rs.

#[repr(transparent)]
pub struct IovIterDest<'data> {
    iov: Opaque<bindings::iov_iter>,
    /// Represent to the type system that this value contains a pointer to readable data it does
    /// not own.
    _source: PhantomData<&'data [u8]>,
}

In this piece of code, several of Rust’s safety mechanisms are at work, namely lifetime tracking and null pointer safety, all while keeping the same memory footprint as the C code would have.

By using 'data as the lifetime of this struct, if you create IovIterDest from a buffer, the compiler forces that the buffer outlives IovIterDest, preventing use-after-free vulnerabilities. By wrapping the struct bindings::iov_iter, you make sure that IovIterDest is always constructed from a valid and non-null reference, effectively moving the null check to the initialization. Because Opaque is wrapping the iov_iter, it prevents you from modifying fields manually. The programmer is forced to use the kernel’s provided functions and therefore the C side’s invariants are kept intact. And since the PhantomData and Opaque wrapper have no runtime footprint, the machine code compiled from this struct is identical to a raw struct iov_iter *. You can have your cake and eat it!

TL;DR

Rust uses zero-code abstractions like Opaque<T> and PhantomData<T> in order to perform static code analysis. The PhantomData<T> marker informs the compiler about lifetimes, ownership and variance for types it doesn’t actually store at runtime. Opaque<T> is a wrapper that marks a struct as being owned by the C code, and therefore prevents the Rust compiler from making unsafe assumptions about initialization, aliasing or thread-safety of the object. Last but not least, by treating distinct C handles (like DeviceHandle vs DriverHandle) as incompatible types, the compiler can guarantee type safety in the Rust code even if in the C code it boils down to a mere *mut c_void.
