The C Cleanup Pattern

While in most programming styles using goto’s is frowned upon, in the Linux Kernel this is the default method of undoing the registration and creation work done by each driver. You oftentimes have the situation that you start registering a driver. When an error occurs in this process, you have to roll back everything you just did in reverse order. This is where goto comes in handy. By stacking the goto labels, you only undo the work you have already done.

An example of the cleanup pattern used in the Linux Kernel C code can be found in drivers/block/aoe/aoeblk.c, which implements block device routines for the ATA over Ethernet (AoE) network protocol. This driver allows a computer to access hard drives over a standard Ethernet network as if they were locally attached IDE/SATA drives.

/* blk_mq_alloc_disk and add_disk can sleep */
void
aoeblk_gdalloc(void *vp)
{
    // ...
    mp = mempool_create(MIN_BUFS, mempool_alloc_slab, mempool_free_slab,
        buf_pool_cache);
    if (mp == NULL) {
        printk(KERN_ERR "aoe: cannot allocate bufpool for %ld.%d\n",
            d->aoemajor, d->aoeminor);
        goto err;
    }

    // ...
    err = blk_mq_alloc_tag_set(set);
    if (err) {
        pr_err("aoe: cannot allocate tag set for %ld.%d\n",
            d->aoemajor, d->aoeminor);
        goto err_mempool;
    }

    gd = blk_mq_alloc_disk(set, &lim, d);
    if (IS_ERR(gd)) {
        pr_err("aoe: cannot allocate block queue for %ld.%d\n",
            d->aoemajor, d->aoeminor);
        goto err_tagset;
    }

// ...
    err = device_add_disk(NULL, gd, aoe_attr_groups);
    if (err)
        goto out_disk_cleanup;
    aoedisk_add_debugfs(d);
// ...
    return;

out_disk_cleanup:
    put_disk(gd);
err_tagset:
    blk_mq_free_tag_set(set);
err_mempool:
    mempool_destroy(mp);
err:
    spin_lock_irqsave(&d->lock, flags);
    d->flags &= ~DEVFL_GD_NOW;
    queue_work(aoe_wq, &d->work);
    spin_unlock_irqrestore(&d->lock, flags);
}

We see stacked cleanup code. Instead of having a pyramid of deeply nested if statements, the success path is mostly flat. Only in the case of errors, we jump to the cleanup label stack. If creating the memory pool failed, we have to queue the work again for a next try. If the memory pool was created successfully, but we fail to allocate a tag set, we have to roll back the successfully executed code paths in reverse order. You can clearly see where a resource is acquired and what cleanup is necessary to reverse this step.

And the functions called are usually also very similar to what has to be executed when you want to unregister the device or unload a module. Wouldn’t it be great to have this cleanup routine gathered in one place?

Enter Rust’s Drop Trait

Rust introduces actually useful object-oriented patterns to low level programming. It follows the principles of the RAII (Resource Acquisition is Initialization) pattern where the lifecycle of a resource (memory, file handles, locks) is tied to the lifecycle of a value.

When a value is no longer needed (e.g. goes out of scope), Rust will run a “destructor” on it. The destructor consists of two components. First, if the Drop trait is implemented for its type, the function Drop::drop is called for that value. After that, the destructors of all fields of that value are called in order of their declaration in the struct. The Rust compiler generates the “drop glue” code for this type automatically. In practice, Drop::drop only needs to be implemented for types that directly manage resources¹. If your driver allocated memory, opened a file or a network socket, the cleanup of those resources should happen here.

#[lang = "drop"]
#[stable(feature = "rust1", since = "1.0.0")]
#[rustc_const_unstable(feature = "const_destruct", issue = "133214")]
pub const trait Drop {
    #[stable(feature = "rust1", since = "1.0.0")]
    fn drop(&mut self);
}

We can find several examples of the usage of this trait in the current upstream Linux kernel 7.0-rc6. For now, most current Rust kernel drivers merely call the release function or free up resources using C bindings.

The Drop trait is implemented for the clock driver in rust/kernel/clk.rs. All this driver has to do is decrement the reference count for the clock instance, which is done in this case by calling the C function clk_put using bindings.

impl Drop for Clk {
    fn drop(&mut self) {
        // SAFETY: By the type invariants, self.as_raw() is a valid argument for [`clk_put`].
        unsafe { bindings::clk_put(self.as_raw()) };
    }
}

Compared to the clock driver, the implementation of drop for the red black tree has to do more work. It has to iterate through all nodes in the tree, remembering the next node and freeing the memory allocated on the heap for each node by calling the drop function on each KBox element.

impl<K, V> Drop for RBTree<K, V> {
    fn drop(&mut self) {
        // SAFETY: `root` is valid as it's embedded in `self` and we have a valid `self`.
        let mut next = unsafe { bindings::rb_first_postorder(&self.root) };

        // INVARIANT: The loop invariant is that all tree nodes from `next` in postorder are valid.
        while !next.is_null() {
            // SAFETY: All links fields we create are in a `Node<K, V>`.
            let this = unsafe { container_of!(next, Node<K, V>, links) };

            // Find out what the next node is before disposing of the current one.
            // SAFETY: `next` and all nodes in postorder are still valid.
            next = unsafe { bindings::rb_next_postorder(next) };

            // INVARIANT: This is the destructor, so we break the type invariant during clean-up,
            // but it is not observable. The loop invariant is still maintained.

            // SAFETY: `this` is valid per the loop invariant.
            unsafe { drop(KBox::from_raw(this)) };
        }
    }
}

How Drop Works

Dropping a value can be triggered in different scenarios. One trigger is when a value goes out of scope, which happens at the end of a block {..} or when a function returns. Furthermore, when you assign a new value to an existing variable, the old variable is dropped. It is also possible to call core::mem::drop(x) in the kernel explicitly. In most cases, this is not advised, because it circumvents the compiler’s drop check.

One of the most powerful aspects of this system is how it interacts with the question mark operator (?). In C, if you have five initialization steps and the fourth fails, you must manually goto the specific label that undoes exactly three steps.

In Rust, if you return early with ?, the compiler’s drop check knows exactly which local variables have been initialized at that specific line of code. It will call drop on only those active variables in reverse order. Conversely, if the function succeeds and returns a value, that value is moved to the caller. Rust recognizes this transfer of ownership and ensures the destructor is not called for the returned value, while still cleaning up all other local temporaries in the scope.

The rust lang file core/ops/drop.rs gives an idea of the order of destruction. Local variables are dropped in reverse order of declaration, like on a stack, ensuring that if a later variable depends on an earlier one, the dependency is still valid during the later variable’s cleanup.

Struct fields and collections on the other hand are dropped in order of declaration. The cleanup process for structs is a systematic, recursive traversal of the value’s fields to ensure that every resource it owns is properly released. This specialized destructor that recursively visits every part of the structure is called drop glue and is generated at compile time.

The “drop check” analysis determines whether it is safe to drop a value and its fields recursively. In particular, the compiler needs to keep track of types and lifetimes, and which of them still needs to be live when T gets dropped. If a value does not need to free any resources, there is no need to add a Drop implementation.

The strategy in Rust for making sure no value is forgotten to be dropped is to traverse structs recursively until it reaches a leaf node. Leaf nodes are types that do not own anything, and therefore don’t require their own drop logic. Examples of leaf nodes are primitive types like i32, bool, references and raw pointers and function items and function pointers, which are just addresses of code in memory.

If a type implements the Drop trait, its Drop::drop method is called before its fields drop methods, making sure that the fields can be used one last time during the cleanup process. Think of a struct owning a file descriptor. You want to close the file before its memory is freed and the descriptor becomes invalid.

The drop behavior of enums depends on which variant. In the case of Result<T, E> or Option<T>, each of Some(T) vs None or Ok(T) vs Err(E) requires a different drop logic. Only active variants are dropped, and unused variants don’t need a cleanup. ²

Rust, being the “having its cake and eating it too” language that it is, ensures at compile time that the drop function will be called when our value goes out of scope, removing the human error of forgetting to free memory or flushing a buffer.

Beyond Memory: All Resources

Freeing memory or releasing a resource is not the only action the programmer might want to do. Different drivers will have different requirements. For example, if a bus driver is released, it will want to call the release functions of all the devices attached to it. When a network socket goes out of scope, it will want to gracefully shut down the TCP connection by initiating a TCP FIN handshake, flush the receive and transmit buffers and release the port/IP tuple.

If a file handle goes out of scope, the reference count on the underlying struct file is decremented. If this count reaches zero, which means all the users of the file are gone, the kernel calls the .release method, flushes pending writes, releases all locks and frees the memory associated with the handle.

For custom hardware resources, virtual memory mappings to physical hardware registers might need to be unmapped. If there was a DMA channel used with the hardware, the active transfers need to be stopped and the DMA engine channel released, so that other drivers can use it.

Besides resources, Rust uses so-called guards to protect a resource or a state change. For example, if a programmer acquires a mutex, they receive a MutexGuard. You never manually call unlock on it. Instead, this lock is tied to the lifetime of the guard object. When the guard object goes out of scope, Rust automatically calls the mutex’s Drop implementation to release the lock, just as mutex_unlock would do. This makes it impossible to forget to unlock, even in complex error paths. However the function is exited, be it a successful return, an early ? error, or a panic, the lock is automatically released when the guard’s lifetime ends.

Interfacing with C: ForeignOwnable Pattern

We had a dive into ForeignOwnable previously, where we learned that this trait is used to transfer ownership between Rust and C code. This functionality makes sure that the Rust value is pinned in memory, which means from the time of creation, it will always have the same memory address, and that it won’t be dropped by Rust’s borrow checker while the C part of the kernel is handling it, even though to the Rust part it looks like the variable is unused. This trait builds a safe bridge between both programming languages.

Comparison: C vs Rust Cleanup

In C, when you add a new resource, you have to edit every cleanup stack in the call chain. The cleanup code tends to be repetitive if it occurs in several places, and it is harder to keep all occurrences in sync when resources change. It is way too easy to miss a cleanup label, or reverse the order of the cleanup, and cause use-after-free or double-free bugs. Rust automates all those scenarios, removing entire bug classes. Error handling becomes simpler, because early returns using the ? operator, match arms and panics all trigger the same deterministic teardown code. Mutexes and Spinlocks get unlocked in the Drop implementation, preventing deadlocks. And since the drop glue code is generated at compile time and inlined, we don’t have a runtime penalty for these safety guarantees.

TL;DR

While C makes it easy to forget some of the cleanup when a value goes out of scope, where the responsibility lies on the shoulders of the programmer, Rust makes it very hard to forget the cleanup. In Rust, the programmer only has to remember once to implement the cleanup code, and the Rust equivalent of a compile time garbage collector makes sure this code is executed any time the value is not needed anymore. Fire and forget the type safe way.
